Prince Bridge Range
The Prince flat bridge range brings the practical use of a wooden walkway or crossing while looking very natural in most garden settings.
Click Here to view full description, dimensions & deliveries.
Please choose your option from the table below before choosing additional extras.
Please swipe left/right on tables to view all sizes/ information.
Speak to an Expert
Want to speak to an expert or order over the phone?
Call us on 01253 205 128
Free Delivery
Free mainland UK delivery on all items!
Assembly Instructions
Watch our video on how to assemble your garden bridge.
Prince Bridge Range
Flat style wooden prince garden bridges are ideal crossings for water features, streams or as a walkway in any setting. Featuring three side rails on each side attached to posts, the Prince bridge range are functional and sturdy bridges. Useful as a pedestrian crossing, anti-slip boards can also be added. Available up to 4.8 meters in length, larger sizes and custom features can be added, just contact us to find out how we can help you find a bridge that meets your needs.
Functional Pedestrian Flat Bridge
Flat style bridges are popular, especially where there may be more pedestrian usage than most types of garden bridge. Looking picturesque in a garden, woodland or any outdoor setting, they provide an easy to traverse walkway.
Dimensions
| Bridge Length | 1000mm | 1200mm | 1500mm | 1800mm | 2100mm | 2600mm | 3000mm | 3500mm | 4000mm | 4800mm |
|---|---|---|---|---|---|---|---|---|---|---|
| Handrail Size | 70×34 | 70×34 | 70×34 | 70×34 | 70×34 | 70×34 | 70x45 | 70x45 | 70x45 | 70x45 |
| 2x Lower Handrail Size | 70×34 | 70×34 | 70×34 | 70×34 | 70×34 | 70×34 | 70×34 | 70×34 | 70×34 | 70×34 |
| Post centres | 425 | 510 | 675 | 770 | 950 | 765 | 930 | 825 | 875 | 1050 |
| Number of posts per balustrade | 3 | 3 | 3 | 3 | 3 | 4 | 4 | 5 | 5 | 5 |
| Height of arch top in centre | 170 | 180 | 180 | 225 | 240 | 280 | 360 | 450 | 385 | 410 |
| Underside clearance | 60 | 90 | 90 | 130 | 145 | 175 | 240 | 340 | 165 | 190 |
| Post sizes | 70×70 | 70×70 | 70×70 | 70×70 | 70×70 | 70×70 | 70×70 | 70×70 | 70×70 | 70×70 |
Handrails height above deck (for anti slip boards add 8mm)
| Bridge size/ Handrail height above boards in mm | 1000mm | 1200mm | 1500mm | 1800mm | 2100mm | 2600mm | 3000mm | 3500mm | 4000mm | 4800mm |
|---|---|---|---|---|---|---|---|---|---|---|
| 600mm | 600 | 600 | 700 | 800 | 800 | 900 | 900 | 900 | NA | NA |
| 900mm | 700 | 700 | 850 | 900 | 900 | 900 | 900 | 900 | 1000 | 1000 |
| 1200mm | 700 | 700 | 850 | 900 | 900 | 900 | 900 | 900 | 1000 | 1000 |
Deliveries
1m – 3.5m bridges – standard delivery 5-8 working days (turbo deliver 2-4 working days). If you required timed or weekend delivery please contact us for a price.
4m – 4.8m bridges – standard delivery 8-20 working days (please call for turbo delivery quote). These may be delivered in Kit form by HGV on the pallet network. Please be prepared to off load them from the lorry by fork lift or manually (will require minimum 2x persons). If you required timed or weekend delivery please contact us for a price.
Delivery timescales are approximate and in rare occasions delivery timescales can be shorter or longer depending on our workload. Please bear in mind we build our own products to order and and peak times it can be difficult to match supply to demand.
